Avant 800
Series

The Avant 800 series is the largest and most powerful compact loader in the range. This machine offers the highest lifting capacity of up to 1900 kg. With a strong boom construction and double lift rams this really is a heavy-duty compact loader. The telescopic boom is standard, and the high-flow auxiliary hydraulics will run all attachments from Avant’s range.

Powered by a Stage V, 57HP Kohler and Poclain drive motors with the Avant OPTIdrive system, this is the mother of all compact mini loaders.

A wide variety of attachments are available with everything from general buckets through to specialised tools such as cutting bars and flail mowers. Please note that all front-end attachments are sold separately.

Configure Your Own AvantDownload Brochure
Avant 800 Series

Available Models

Specifications - Avant 860i

Length 3395 mm
Width 1490 mm
Height 2200 mm
Weight 2540 kg
Tyres 380/55-17” tractor profile
Transmission Hydrostatic, Avant OptidriveTM
Drive speed max. 30 km/h
Auxiliary hydraulics 80 l/min
Turning radius inside / outside 1370 / 2990 mm
Lifting height 3500 mm
Tipping load * 1900 kg
Breakout force @ 500 mm 2200 kg
Engine make and type Kohler KDI 1903TCR
Engine output (ECE R120) 42 kW (57 hp)
Torque max. 225 Nm @ 1500 rpm
Fuel Diesel

* Load is measured at 400 mm from the attachment coupling plate, including attachment weight (70 kg) and with counterweights.

Dimensions - Avant 860i

Avant 860i dimensions from the side. Avant 860i dimensions from the front.

Optional Extras

The range of Avant loaders is available with a wide variety of different options and attachments. This includes everything from general buckets to specialised tools such as cutting bars and flail mowers. We have a page dedicated to the range which you can access below. Please note that all front-end attachments are sold separately.

Avant Attachments
