Avant 700
Series

Avant 700 series multipurpose loaders are the second largest and most powerful in the range with a lift capacity of up to 1500kg on the 760i. This popular compact loader features high-flow auxiliary hydraulics that can run all attachments from the Avant range. The telescopic boom comes as standard and provides a lift height of up to 3.1m.

Powered by a Tier 4 Final and Euro stage IIIB emission regs, 57HP Kohler, there is no requirement for a particulate filter nor AdBlue. The 700 series can be purchased as standard with certified ROPS and FOPS or you can choose the full heated cab with the options of air conditioning and sound system.

A wide variety of attachments are available with everything from general buckets through to specialised tools such as cutting bars and flail mowers. Please note that all front-end attachments are sold separately.

Configure Your Own AvantDownload Brochure
Avant 700 series loader.

Available Models

Specifications - Avant 735

Length 3060 mm
Width 1030 - 1305 mm
Height 2060 mm
Weight 1800 kg
Standard Wheels 320/60-12 HD TR
Transmission, Drive Hydrostatic Avant Optidrive™
Pulling Force Max. 1200 kp
Drive Speed Max. 11 km/h
Aux. Hydraulics Oil Flow / Pressure 50 l/min 200 bar
Turning Radius Inside/Outside 1240 / 2780 mm
Max. Lifting Height 3080 mm
Max. Tipping Load 1400 kg
Max. Breakout Force / 50 cm 1700 kg
Engine Make & Type Kubota V1505 Stage V, 4-cyl.
Engine Output (ECE R120) 19 kW (26 hp)
Maximum Torque 93 Nm @ 1700 rpm
Fuel Diesel



Dimensions - Avant 735

Avant 735 dimensions from the side. Avant 735 dimensions from the front.

Specifications - Avant 755i

Length 3060 mm
Width 1030 - 1360 mm
Height 2060 mm
Weight 1970 kg
Standard Wheels 320/60-12HD TR
Transmission, Drive Hydrostatic Avant Optidrive™
Pulling Force Max. 1330 kp
Drive Speed Max. 17 km/h
Aux. Hydraulics Oil Flow / Pressure 80 l/min 225 bar
Turning Radius Inside/Outside 1240 / 2780 mm
Max. Lifting Height 3080 mm
Max. Tipping Load 1400 kg
Max. Breakout Force / 50 cm 1700 kg
Engine Make & Type Kohler KDI 1903 TCR Stage V
Engine Output (ECE R120) 42 kW (57 hp)
Maximum Torque 220 Nm @ 1500 rpm
Fuel Diesel



Dimensions - Avant 755i

Avant 755i dimensions from the side. Avant 755i dimensions from the front.

Specifications - Avant 760i

Length 3060 mm
Width 1400 - 1450 mm
Height 2110 mm
Weight 2100 kg
Standard Wheels 400/50-15 TR
Transmission, Drive Hydrostatic Avant Optidrive™
Pulling Force Max. 1880 kp
Drive Speed Max. 26 km/h
Aux. Hydraulics Oil Flow / Pressure 80 l/min 225 bar
Turning Radius Inside/Outside 1240 / 2780 mm
Max. Lifting Height 3100 mm
Max. Tipping Load 1400 kg
Max. Breakout Force / 50 cm 1700 kg
Engine Make & Type Kohler KDI 1903 TCR Stage V
Engine Output (ECE R120) 42 kW (57 hp)
Maximum Torque 220 Nm @ 1500 rpm
Fuel Diesel



Dimensions - Avant 760i

Avant 760i dimensions from the side. Avant 760i dimensions from the front.

Optional Extras

The range of Avant loaders is available with a wide variety of different options and attachments. This includes everything from general buckets to specialised tools such as cutting bars and flail mowers. We have a page dedicated to the range which you can access below. Please note that all front-end attachments are sold separately.

Avant Attachments
