Avant 700
Series

Avant 700 series multipurpose loaders are the second largest and most powerful in the range with a lift capacity of up to 1500kg on the 760i. This popular compact loader features high-flow auxiliary hydraulics that can run all attachments from the Avant range. The telescopic boom comes as standard and provides a lift height of up to 3.1m.

Powered by a Tier 4 Final and Euro stage IIIB emission regs, 57HP Kohler, there is no requirement for a particulate filter nor AdBlue. The 700 series can be purchased as standard with certified ROPS and FOPS or you can choose the full heated cab with the options of air conditioning and sound system.

A wide variety of attachments are available with everything from general buckets through to specialised tools such as cutting bars and flail mowers. Please note that all front-end attachments are sold separately.

Configure Your Own AvantDownload Brochure
Avant 700 series loader.

Available Models

Specifications - Avant 735

Length 3060 mm
Width 1290 mm
Height 2060 mm
Weight 1800 kg
Standard wheels 320/60-12 HD TR
Transmission, drive Hydrostatic Avant OptidriveTM
Aux. hydraulics oil flow / pressure 50 l/min 200 bar
Turning radius inside/outside 1240 / 2780 mm
Max. lifting height 3080 mm
Tipping load * 1400 kg
Max. breakout force / 50 cm 1700 kg
Engine make and type Kubota V1505 Stage V, 4-cyl.
Engine output (ECE R120) 19 kW (26 hp)
Fuel Diesel

* Load is measured at 400 mm from the attachment coupling plate, including attachment weight (70 kg) and with counterweights.

Dimensions - Avant 735

Avant 735 dimensions from the side. Avant 735 dimensions from the front.

Specifications - Avant 755i

Length 3060 mm
Width 1030 - 1360 mm
Height 2060 mm
Weight 1970 kg
Standard wheels 320/60- 12 Tractor
Transmission, drive Hydrostatic
Aux. hydraulics oil flow / pressure 80 l/min @ 225 bar
Turning radius inside/outside 1240 / 2780 mm
Max. lifting height 3100 mm
Tipping load * 1400 kg
Max. breakout force / 50 cm 1700 kg
Engine make and type Kohler KDI 1903 TCR
Engine output (ECE R120) 42 kW (57 hp)
Fuel Diesel

* Load is measured at 400 mm from the attachment coupling plate, including attachment weight (70 kg) and with counterweights.

Dimensions - Avant 755i

Avant 755i dimensions from the side. Avant 755i dimensions from the front.

Specifications - Avant 760i

Length 3060 mm
Width 1400 - 1450 mm
Height 2110 mm
Weight 2100 kg
Standard wheels 400/50-15 TR
Transmission, drive Hydrostatic
Aux. hydraulics oil flow / pressure 80 l/min @ 225 bar
Turning radius inside/outside 1240/2780 mm
Max. lifting height 3100 mm
Max. lifting capacity (hydr.) 2100 kg
Tipping load * 1400 kg
Max. breakout force / 50 cm 1700 kg
Engine make and type Kohler KDI 1903 TCR
Engine output (ECE R120) 42kW (57 hp)
Fuel Diesel

* Load is measured at 400 mm from the attachment coupling plate, including attachment weight (70 kg) and with counterweights.

Dimensions - Avant 760i

Avant 760i dimensions from the side. Avant 760i dimensions from the front.

Optional Extras

The range of Avant loaders is available with a wide variety of different options and attachments. This includes everything from general buckets to specialised tools such as cutting bars and flail mowers. We have a page dedicated to the range which you can access below. Please note that all front-end attachments are sold separately.

Avant Attachments
