Avant 400
Series

The Avant 400 series mini loader is a light and economical workhorse, perfect for stables, farming and private use. Its narrow width allows passage through restricted paths and gateways. They are simple and easy to use thanks to articulated steering and hydrostatic transmissions. The telescopic boom is standard and is powered by Kubota.

A wide variety of Avant attachments are available with everything from general buckets to specialised tools such as cutting bars and flail mowers. Please note that all front-end attachments are sold separately.

Configure Your Own AvantDownload Brochure
Avant 400 Series

Key Features

  • Light and economical to operate
  • Perfect farming, stables and many other uses
  • Simple and easy to operate
  • Articulated steering and hydraulic transmission
  • Wide range of attachments available
  • Telescopic boom available as an option
  • L cab available as an option

Available Models

Specifications - Avant 423

Length 2195 mm
Width 990 - 1090 mm
Height 1980 mm
Weight 1030-1080 kg
Standard Wheels 23x8.50-12” grass/TR
Transmission, Drive Hydrostatic
Pulling Force Max. 700 kp
Drive Speed Max. 12 km/h
Auxiliary Hydraulics Oil Flow / Pressure 34 l/min 185 bar
Turning Radius Inside / Outside 880 / 1970 mm
Max. Lifting Height 2750 mm
Max. Tipping Load 550 kg
Engine Make & Type Kubota D902 Stage V
Engine Output (ECE R120) 16 kW (22 hp)
Maximum Torque 56 Nm @ 2600 rpm
Fuel Diesel



Dimensions - Avant 423

Avant 423 dimensions from the side.       Avant 423 dimensions from the front.

Optional Extras

The range of Avant loaders is available with a wide variety of different options and attachments. This includes everything from general buckets to specialised tools such as cutting bars and flail mowers. We have a page dedicated to the range which you can access below. Please note that all front-end attachments are sold separately.

Avant Attachments
