Avant e
Series

Avant e series compact loaders are 100% electrically powered and perfect for indoor use where ventilation is limited. This battery powered electric loader has zero emissions, helping to improve your environmental credentials. Catering for farmers with livestock, equestrian centres with indoor horse arenas and clients who generate their own electricity.

Powered by either AGM (Absorbent Glass Mat) batteries or quick charging lithium-ion batteries and built in battery chargers, the Avant e series is a very quiet, clean and powerful electric compact loader for the modern age of farming.

A wide variety of attachments are available with everything from general buckets through to specialised tools such as cutting bars and flail mowers. Please note that all front-end attachments are sold separately.

Download Brochure
Avant E series loaders.

Key Features

  • Battery powered with zero emissions
  • Very quiet electric motor
  • Low operating costs
  • Integrated battery charger as standard
  • Can be operated whilst charging the batteries
  • Equipped with a certified ROPS safety canopy and FOPS safety roof as standard
  • Optidriveâ„¢ drive circuit developed by Avant improves the performance of the loader by even 10 %
  • The same quick attach and multi connector systems as used in other Avant models
  • A full range of attachments are available

Available Models

Specifications - Avant e5

Length 2550 mm
Width (with standard wheels) 1130 mm
Height 1985 mm
Weight 1590 kg
Standard tyres 23x10.50-12
Transmission, drive Hydrostatic
Drive speed max. 10 km/h
Auxiliary hydraulics oil flow / pressure 30 l/min
Hydraulic oil cooler Standard
Turning radius inside/outside 995 / 2050 mm
Max. lifting height (with telescopic boom) 2790 mm
Max. lifting capacity (hydr.) 1350 kg
Tipping load * 900 kg
Max. breakout force / 50 cm 1100 kg
Battery type Lead-acid
Battery capacity 11,5 kWh
Fuel Electric

* Lift capacity with a 90 cm pallet



Avant e5 8 hour working day graphic.

Dimensions - Avant e5

Avant e5 dimensions from the side. Avant e5 dimensions from the front.



Specifications - Avant e6

Length 2550 mm
Width (with standard wheels) 1130 mm
Height 1985 mm
Weight 1400 kg
Standard tyres 23x10.50-12"
Transmission, drive Hydrostatic
Drive speed max. 10 km/h
Auxiliary hydraulics oil flow / pressure 30 l/min
Hydraulic oil cooler Standard
Turning radius inside/outside 995 / 2050 mm
Max. lifting height (with telescopic boom) 2790 mm
Max. lifting capacity (hydr.) 1350 kg
Tipping load * 760 kg
Max. breakout force / 50 cm 1100 kg
Battery type Lithium-ion
Battery capacity 13,8 kWh
Fuel Electric

* Lift capacity with a 90 cm pallet

Avant e6 8 hour working day graphic.

Dimensions - Avant e6

Avant e6 dimensions from the side. Avant e6 dimensions from the front.

Optional Extras

The range of Avant loaders is available with a wide variety of different options and attachments. This includes everything from general buckets to specialised tools such as cutting bars and flail mowers. We have a page dedicated to the range which you can access below. Please note that all front-end attachments are sold separately.

Avant Attachments
