The Leguan 225 is an all-terrain spider lift with unrivalled performance over its predecessors thanks to a maximum working height of 22.5m, maximum outreach of 11.2m and a maximum lifting capacity of 250kg.
The advanced all-terrain capabilities and rapid driving speeds make the Leguan 225 the optimal choice for the most challenging environments. The design of the spider lift’s boom provides maximum outreach, even at considerable heights. With intuitive joystick controls, facilitating concurrent movements, this platform’s control interface guarantees quick and smooth movements of the boom.
The smart features of the Leguan 225 minimise operational issues and enhance productivity, allowing you to concentrate on the task at hand. The boom is well-protected against external impacts including falling branches and sawdust, making the 225 a great choice for both arborists and construction professionals alike.
Download Brochure
Key Features
- 21 hp Kubota diesel engine + 230 V electric motor
- 230 V and USB power outlets on platform
- Automatic engine RPM control
- Automatic levelling of the outriggers
- Proportional outreach monitoring system
- Electric rotation of the platform
- JIB-boom with 120-degree operating range
- Battery powered emergency lowering system
- Lower controls with integrated service display
- Signal horn
Specifications
| Max Lift Capacity | 250 kg (2 persons) |
|---|---|
| Max Working Height | 22.5 m |
| Max Platform Height | 20.5 m |
| Max Outreach | 9.1m (250 kg) - 11.2m (120 kg) |
| Transport Dimensions (L x W x H) | 6.03m x 1.33m x 2.2m |
| Platform Dimensions | 1.33m x 0.75m |
| Rotation of The Platform | 110º (±55º) |
| Slewing | 360º |
| Gradeability | 45% (25º) |
| Outrigger Support Dimensions | 4.08 x 4.08m |
| Max Slope for Outriggers | 25% (14º) |
| Weight | 2950 kg |
| Engine | Kubota 21 hp diesel or 230 V / 2.2 kW electric |
| Drive System (Hydraulic) | Tracks |
| Max Drive speed | 3.1 km/h |
Optional Extras
- Remote control for driving and outriggers
- LED spot lights for platform
- Tool trays on platform
- Outrigger beacons
- Hose to platform (air/water)
- Engine heater
- Non-marking tracks
- Narrow single person platform
- Leguan special trailer
